Truck type
Mercedes 1419
External Dimensions
Length 12 meters
Width steps included: 6 meters
Lighting
Dimmable TL – Lights 2 x 9,5 meters
Full RGB LED: 2 x 9,5 meter
Led Controller MBN L5830
DMX 512 controllable
Master/slave mode
Plugs
11 interior (220V)
2 exterior (220V)
Air conditioning
2 x airco
Capacity cooling: 2x 4,39 Kw
Capacity heating: 2 x 3.72 Kw
Sun screen
Front, exterior
Width: 3,5 meters
Length: 9,5 meter
Flagpoles
2, next to the stairs, outer corners
Promotional panel
Next to the stairs length: 9,5 meters x 65 cms
Daylight
3 skylights and 3 lateral windows provide beautiful daylight
Whiteboard
The white walls can be used as a whiteboard for presentations, schedules, etc
Cargo space
The middle part cannot be use as a cargo space because these parts are being lifted during transport.
The lateral parts can be used as a cargo space (18m²)
Wrap advertising
Possible
How is electricity being provided
Through a 3 phase contact (380V) or a 1 phase contact
Optional: an electric generator when there is no other way to provide electricity
